Spring-loaded pins are widely used in PCB designs for temporary and permanent electrical connections. While they offer flexibility, they come with inherent drawbacks such as wear, contact resistance issues, and mechanical failure over time.
For engineers designing high-reliability electronic systems, Z-Axis elastomeric connectors provide a superior alternative—offering lower resistance, longer lifespan, and more robust performance.
The Challenges with Spring-Loaded Pins
Spring-loaded pins are often chosen for their ability to handle misalignment and their ease of use in test fixtures and interconnect systems. However, they introduce several limitations:
- Mechanical Wear & Tear
- The constant compression and decompression of the spring mechanism lead to mechanical failure, limiting the pin’s lifespan.
- High Contact Resistance
- Over time, oxidation, contamination, and mechanical degradation increase resistance, affecting signal integrity.
- Space & Cost Constraints
- Spring-loaded pins require larger footprints, precise alignment, and costly manufacturing, making them less ideal for compact designs.
- Environmental Sensitivity
- Exposure to vibration, shock, or extreme temperatures can degrade the mechanical integrity of spring-loaded contacts.
Why Elastomeric Connectors Outperform Spring-Loaded Pins
Z-Axis elastomeric connectors offer a more reliable, compact, and cost-effective alternative for engineers looking to improve their PCB interconnect designs. Here’s why:
- High-Density Contact Array
- Our elastomeric connectors feature soft silicone and redundant gold-plated conductors, ensuring a reliable, low-resistance connection without the need for a spring mechanism. The spring mechanism is inherent in the design.
- Long-Term Durability
- With no moving parts, elastomeric connectors eliminate mechanical failure due to repeated compression cycles.
- Low & Stable Contact Resistance
- Unlike spring-loaded pins, which degrade over time, elastomeric connectors maintain consistent electrical performance.
- Compact & Scalable
- These connectors support high-density PCB layouts, making them ideal for miniaturized applications where space is critical.
- Shock & Vibration Resistance
- Elastomeric materials absorb mechanical stress, providing stable connections even in harsh environments.
Applications for Elastomeric Connectors
Replacing spring-loaded pins with elastomeric connectors can significantly enhance reliability across various applications:
- Board-to-Board Connections
- Flexible and low-profile elastomeric connectors simplify stacking PCBs without bulky mechanical components.
- Test & Burn-In Sockets
- Ideal for high-cycle testing applications where consistent, repeatable contact is required.
- Portable & Rugged Devices
- Suitable for handheld electronics, aerospace, and defense applications where vibration resistance is crucial.
- High-Speed Signal Applications
- The low inductance and capacitance of elastomeric connectors support high-frequency signals with minimal interference.
Upgrade Your PCB Design Today
If you’re dealing with spring-loaded pin failures, unreliable test contacts, or space constraints in your PCB layouts, it’s time to explore a better solution. Z-Axis elastomeric connectors provide a superior electrical and mechanical connection, ensuring long-term reliability and performance in even the most demanding applications.
Looking for a customized solution? Our engineering team can help you integrate elastomeric connectors into your next design. Contact us today to learn more!
